Description
The Binocular Infinity Plan Laboratory Biological Microscope YR05787 – YR05788 is an advanced microscopy tool designed for precision in laboratory settings. With a binocular head that inclines 30° and is rotatable 360°, it ensures user comfort over extended viewing periods. This microscope features an integrated eyepiece lens barrel that protects against loss and contamination, lending it robustness and reliability. It comes equipped with high eyepoint eyepieces and offers a variety of objective lenses—Achromatic, Plan, Infinity E-Plan, and Infinity Plan—catering to different research needs. Its mechanical stage and precise focusing capabilities enhance the operational ease, making it an indispensable tool for detailed biological examinations.
Market Price
The pricing for laboratory microscopes like the Binocular Infinity Plan Laboratory Biological Microscope typically ranges between $700 USD to $1500 USD, depending on the features and specifications offered. This positioning provides an excellent value for its precision engineering and versatility in complex biological applications.
Frequently Asked Questions
- What type of objectives does this microscope support? This microscope supports Plan, Infinity E-Plan, and Infinity Plan objectives, allowing high-quality imaging.
- Is the illumination system effective for all types of samples? Yes, it includes a 3W-LED illumination system, supported by a halogen lamp, which ensures excellent lighting for various sample types.
- Can this microscope be used for both educational and professional purposes? Its advanced features and ease of use make it suitable for both educational settings and professional laboratory research.
Advantages and Disadvantages
Advantages: This microscope offers high customization with interchangeable objectives and illumination options, robust build quality for long-term use, and ergonomic design for user comfort. Disadvantages: The advanced features might be overwhelming for beginners without prior microscopy experience.
Field Use
In practical scenarios, the Binocular Infinity Plan Laboratory Biological Microscope YR05787 – YR05788 is used extensively in biological research laboratories for cell biology and histology. Its precise focusing and clear imaging capabilities make it ideal for intricate analysis and documentation of specimens.
Recommendations
To maximize the performance of your microscope, regular cleaning and maintenance of the lenses are recommended. When adjusting the focus or changing objectives, handle delicately to preserve the integrity of the components. For best results in mobile settings, consider using the power bank supply for LED illumination.
Features
- Binocular Seidentopf head, inclined 30° and rotatable 360°
- High eyepoint eyepiece with interpupillary distance adjustment
- Quadruple and quintuple backward-facing nosepiece options
- Mechanical stage with travel dimensions of 76mm x 52mm
- 3W-LED illumination with optional halogen lamp
- Abbe condenser with N.A. 1.25 and iris diaphragm
Technical Specifications
Model | Cata. No. | YR05787 | YR05788 | |
Head | Seidentopf Binocular Head Inclined 30°,Rotatable 360°, Interpupilary Distance 48-75mm | YR05788-op1 | ● | ○ |
Seidentopf Trinocular Head Inclined 30°,Rotatable 360°, Interpupilary Distance 48-75mm, Light Split Fixed P20:E80 | YR05788-op2 | ○ | ● | |
WF10X/20mm (High Eyepoint) | YR05788-op3 | ●● | ●● | |
Nosepiece | Quadruple, Backward | YR05788-op4 | ● | ● |
Quintuple, Backward | YR05788-op5 | ○ | ○ | |
Infinity Plan Objectives | PLAN 2.5x/0.07,W.D.=8.47mm | YR05788-op6 | ○ | ○ |
PLAN 4X/0.10.W.D.=12.1mm | YR05788-op7 | ● | ● | |
PLAN 10X/0.25.W.D.=4.64mm | YR05788-op8 | ● | ● | |
PLAN 20X/0.40(S).W.D.=2.41mm | YR05788-op9 | ○ | ○ | |
PLAN 40X/0.66(S).W.D.=0.65mm | YR05788-op10 | ● | ● | |
PLAN 60X/0.80(S).W.D.=0.33mm | YR05788-op11 | ○ | ○ | |
PLAN 100X/1.25(S,Oil).W.D.=0.12mm | YR05788-op12 | ● | ● | |
PLAN 100X/1.15(S,Water).W.D.=0.19mm | YR05788-op13 | ○ | ○ | |
Working Stage | Mechanical Stage Size: 145 mm×140mm, Travel: 76mmX52mm, Scale: 0.1mm, Double Slide Holder | YR05788-op14 | ● | ● |
Rackless (Integrated) Stage, Size 140×135mm, | YR05788-op15 | ○ | ○ | |
Travel Range 75×35mm, Double Slide Holder | – | |||
Focusing | Coaxial Coarse & Fine Focusing, Coarse Focusing Travel Range: 26mm, Fine Focusing Travel Range: 2µm/Division | YR05788-op16 | ● | ● |
Condenser | Abbe Condenser N.A.1.25, Iris Diaphragm, Rack & Pinion Up/Down, With Filter Holder | YR05788-op17 | ● | ● |
Illumination | 3W-LED Illumination Systems | YR05788-op18 | ● | ● |
Powered By Safety Low Voltage Charger, Input Wide Voltage 100V-240V, Output 5V1A, Support Power Bank Supply For Outdoor Use | – | |||
12V/20W Halogen Lamp, Power Supply Wide Voltage 100V~240V | YR05788-op20 | ○ | ○ | |
6V/30W Halogen Lamp, Power Supply Wide Voltage 100V~240V | YR05788-op21 | ○ | ○ | |
Field Diaphragm | Upgrade To Kohler Illumnation | YR05788-op22 | ○ | ○ |
Filter | Dia.45mm, Blue | YR05788-op23 | ○ | ○ |
Dia.45mm, Green | YR05788-op24 | ○ | ○ | |
Dia.45mm, Yellow | YR05788-op25 | ○ | ○ | |
Dark Field | Dark Field Condenser, Dry, N.A.0.83-0.91, For 4x10x40x Objective | YR05788-op26 | ○ | ○ |
Polarizing | Analyzer + Polarizer Set | YR05788-op27 | ○ | ○ |
Phase Contrast | Infinity Plan Phase Contrast Objective 10x + Phase Contrast Slide 10x + Phase Contrast Condenser + Telescope 11x + Green Filter | YR05788-op28 | ○ | ○ |
Infinity Plan Phase Contrast Objective 20x + Phase Contrast Slide 20x + Phase Contrast Condenser + Telescope 11x + Green Filter | YR05788-op29 | ○ | ○ | |
Infinity Plan Phase Contrast Objective 40x + Phase Contrast Slide 40x + Phase Contrast Condenser + Telescope 11x + Green Filter | YR05788-op30 | ○ | ○ | |
Infinity Plan Phase Contrast Objective 100x + Phase Contrast Slide 100x + Phase Contrast Condenser + Telescope 11x + Green Filter | YR05788-op31 | ○ | ○ | |
Turret Phase Contrast Attachment | YR05788-op32 | ○ | ○ | |
Infinity Plan Phase Contrast Objective 10x20x40x100x, Turret Phase Contrast Condenser 5-Holes, Telescope 11x, Green Filter | – | |||
Adapter | C-Mount 0.5x, Focus Adjustable | YR05788-op33 | ○ | ○ |
C-Mount 0.75x, Focus Adjustable | YR05788-op34 | ○ | ○ | |
Mirror | Reflecting Mirror & Holder | YR05788-op35 | ○ | ○ |
Attachment | Wire Winding Device | YR05788-op36 | ○ | ○ |
Package | Carton Size 390×280×450mm, 1 Unit/Ctn | |||
Weight | Gross Weight: 7.5 kgs, Net Weight: 6.5 kgs | |||
Note:”●”In Table Is Standard outfits,”○”Is Optional Accessories |
