Biological Microscope YR0242-M // YR0242-T

ManufacturerKalstein

Description

The Biological Microscope YR0242-M // YR0242-T offers a comprehensive solution for both educational and professional laboratory settings. With its versatile head options, including monocular, binocular, trinocular, and teaching head, this microscope adapts to various research and teaching needs. The Seidentopf head allows 360° rotation and a comfortable 30° inclination, with adjustable diopter settings for personalized viewing. The device includes a quadruple nosepiece with precise click stops and an integrated mechanical stage, ensuring convenient and accurate specimen handling. The high brightness 3W LED lighting, paired with an Abbe condenser N.A. 1.25, provides exceptional clarity and adjustable illumination for detailed observation.

Market Price

In the market, the Biological Microscope YR0242-M // YR0242-T is typically found within a price range of $300 to $1020. This pricing reflects the superior optical quality and advanced features that are designed to meet the demands of both academic and clinical environments.

Frequently Asked Questions

What is the difference between the YR0242-M and YR0242-T models?
The key difference lies in the head type and video adapter options. The YR0242-M is monocular, while the YR0242-T features a Seidentopf trinocular head, suitable for photomicrography.

Can the lighting source be changed?
Yes, users can choose between halogen 6V20W or LED, depending on their preference for brightness and energy efficiency.

Advantages and Disadvantages

Advantages: The microscope’s modular build, combined with its high-performance optical system, makes it ideal for detailed analysis. Its adaptability to various head types and objectives ensures it caters to a wide range of applications.

Disadvantages: Some users might find the initial setup complex, especially when switching between different heads or adjusting diopters.

Product Usage in the Field

The Biological Microscope YR0242-M // YR0242-T is commonly used in biology labs, medical facilities, and educational institutions. Its advanced optical capabilities make it instrumental in the examination of slides related to anatomy, microbiology, and pathology.

Recommendations

To ensure optimal performance, regular cleaning of the lenses and careful handling of the mechanical stage is recommended. Additionally, users should periodically adjust the tension to maintain smooth focus operations. For convenient and accurate magnification, it is advisable to make use of the entire range of objectives provided: 4X, 10X, 40X, and 100X (oil).

Features

  • Interchangeable monocular, binocular, trinocular, and teaching heads.
  • Quadruple nosepiece with precise click stops.
  • Integrated double layer mechanical stage with a 75x50mm moving range.
  • Adjustable high brightness 3W LED and Abbe condenser N.A. 1.25.
  • Infinity plan and achromatic optical system.
  • Rotatable Seidentopf head with a 30° inclination.

Technical Specifications

Model No. YR0242-M YR0242-B YR0242-T
Video Adapter —— C-Mount 0.3x ——
Power Supply Type AC 110V-240V ——
Transmit Light Halogen 6V20W or LED Optional
Light Source Type Halogen
Condenser N.A. 1.25
Condenser Type Abbe
Condenser Features Rack & Pinionↆ↑, Filter Holder, Center Adjustable
Focusing Scale 0.002mm
Focusing Range 36mm
Focusing Type Coaxial Coarse & Fine ——
Focusing Features Safety Stop Screw Tension Adjustable
Working Stage Moving 75*50mm
Working Stage Size 132*142mm
Working Stage Type 2 Layers Mechanical
Objective Achromatic 4x, 10x, 40x(S), 100x(O,S)
Objective Type Achromatic
Nosepiece Holes 4 Holes
Nosepiece Features Inward
Eyepiece WF10x/18mm
Eyepiece Diameter 23.2mm
Head Interpupillary 54~75mm
Head Rotation Head Rotate 360° ——
Head Inclination 30° ——
Head Type Monocular —— Seidentopf Trinocular
Standard Magnification 40x-1000x ——
Optical System Achromatic
Standard Function BF ——

Additional information

Weight 6 kg
Model

YR0242-B, YR0242-M, YR0242-T
