Benchtop Spectrophotometer YR05477

The Benchtop Spectrophotometer YR05477 offers a high-precision solution for color measurement and analysis across a range of industrial and laboratory applications. With its advanced optical structures, such as reflective d/8 and transmissive d/0 geometry, this versatile device effectively measures both reflectance in objects and transmittance in liquids and transparent or translucent solids. Its compact design, coupled with a 7-inch TFT touch screen and LED and UV light sources, ensures user-friendly operation and consistent data reliability. Perfect for industries like plastics, textiles, paint, and cosmetics, the YR05477 is equipped with significant storage capabilities and sophisticated PC software to meet any color analysis needs.

Market Price

The Benchtop Spectrophotometer YR05477 is priced competitively within the range of $10,400 to $10,800 USD. This strategic investment facilitates enhanced precision and stability in quality control processes, making it stand out among other high-end spectrophotometers. For a custom quote that meets your industry-specific requirements, visit the Kalstein Plus platform to request a quote easily and quickly, with no obligations.

Frequently Asked Questions

• Can the YR05477 handle both opaque and translucent samples? Absolutely, this model is built to measure both opaque and translucent materials, including liquids and transparent solids.
• How much data can this spectrophotometer store? The YR05477 can store up to 20,000 test results, offering a thorough record for detailed analysis.
• Does it allow for adjustable measurement apertures? Yes, you can choose from four apertures: φ25.4 mm, 15 mm, 8 mm, and 4 mm to suit different applications.

Advantages and Disadvantages

The YR05477 provides numerous advantages, including a temperature compensation system for precision in varied climates, the ability to measure in diverse color spaces, and an ergonomic design that supports prolonged use. However, users may find the need for periodic calibration in high-demand environments to uphold its accuracy as a potential downside.

Field Use

Designed for high-demand industries such as automotive, food, cosmetics, and medical sectors, where product appearance and color control are crucial, the YR05477 excels in measuring reflectance and transmittance across various materials. This capability makes it indispensable for quality control and product development labs, optimizing verification processes and ensuring compliance with quality standards at every production phase.

Recommendations

To ensure optimal performance of the YR05477, periodic calibration and maintaining the device in a stable and clean environment is advised. Adjusting the measurement aperture to the sample type and test conditions enhances accuracy and result consistency. Request your personalized quote today with Kalstein Plus and explore how the YR05477 Benchtop Spectrophotometer can revolutionize your quality control and color transfer processes, delivering precise and reliable measurements in every application.

Features

• Advanced optical geometry: Reflective d/8 and transmissive d/0
• 7-inch TFT touch screen for ease of use
• Comprehensive illuminants with LED and UV light sources
• Capacity to store up to 20,000 records
• Versatile PC software included
• Supports multiple color spaces and measurement apertures

Technical Specifications

Model	YR05477
Optical Geometry	Reflect: di:8°, de:8°(diffused illumination, 8-degree viewing angle); SCI (specular component included)/SCE (specular component excluded); Include UV / excluded UV light source. Transmittance: di:0°, de:0° (diffuse illumination: 0° viewing); SCI (specular component included)/SCE (specular component excluded); Include UV / excluded UV light source; Haze(ASTM D1003). Conforms to CIE No.15, GB/T 3978, GB 2893, GB/T 18833, ISO7724/1, ASTM E1164, DIN5033 Teil7
Application	It is used for accurate analysis and transmission of laboratory color. Apply in paints, inks, textiles, garments, printing and dyeing, printing, etc industries for color transfer and quality control.
Integrating Sphere Size	Φ154mm
Light Source	360 nm to 780 nm, Combined LED Light, 400nm cut-off light source
Spectrophotometric Mode	Concave Grating
Sensor	256 Image Element Double Array CMOS Image Sensor
Wavelength Range	360-780nm
Wavelength Interval	10nm
Semiband Width	10nm
Measured Reflectance Range	0-200%
Measuring Aperture	Reflective: Φ30mm/Φ25.4mm, Φ10mm/Φ8mm, Φ6mm/Φ4mm;
	Transmissive: Φ30mm/Φ25mm;
	Remark: 1. Automatic identification of switch caliber 2. Customized Configuration caliber and lens position
Specular Component	Reflectance: SCI&SCE / Transmittance: SCI&SCE
Color Space	CIE LAB, XYZ, Yxy, LCh, CIE LUV, Musell, s-RGB, HunterLab, βxy, DIN Lab99
Color Difference Formula	ΔE * ab, ΔE * uv, ΔE * 94, ΔE * cmc(2:1), ΔE * cmc(1:1), ΔE * 00, DINΔE 99, ΔE (Hunter)
Other Colorimetric Index	WI (ASTM E313, CIE/ISO, AATCC, Hunter),
	YI (ASTM D1925, ASTM 313),
	MI (Metamerism Index),
	Staining Fastness, Color Fastness, Color Strength, Opacity,
	8° Glossiness, Gardner Index, Pt-Co Index, 555 Index, Haze(ASTM D1003)
Observer Angle	2°/10°
Illuminant	D65, A, C, D50, D55, D75, F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12
Displayed Data	Spectrogram/Values, Samples Chromaticity Values, Color Difference Values/Graph, PASS/FAIL Result, Color Offset
Measuring Time	About 2.4s (Measure SCI & SCE about 5s)
Repeatability	Spectral reflectance: Φ25.4mm/SCI, Standard deviation within 0.05% (400 nm to 700 nm: within 0.04%)
	Chromaticity value: Φ25.4mm/SCI, Standard deviation within ΔE*ab 0.02 (When a white calibration plate is measured 30 times at 5-second intervals after white calibration). Spectral Transmittance: Φ25.4mm/SCI, Standard deviation within 0.05% (400 nm to 700 nm: within 0.04%)
	Chromaticity value: Φ25.4mm/SCI, Standard deviation within ΔE*ab 0.03 (When a white calibration plate is measured 30 times at 5-second intervals after white calibration)
Inter-instrument Error	Φ25.4mm/SCI, Within ΔE*ab 0.15
	(Average for 12 BCRA Series II color tiles)
Dimension	L*W*H=370x300x200mm
Weight	Approx. 9.6kg
Power	AC 24V, 3A Power adapter power supply
Illuminant Life Span	5 years, more than 3 million times measurements
Display	7-inch TFT color LCD, Capacitive Touch Screen
Data Port	USB & Print serial port
Data Storage	Standard 2000 Pcs, Sample 20000 Pcs
Language	Simplified Chinese, Traditional Chinese, English
Operating Environment	0~40℃, 0~85%RH (no condensing), Altitude < 2000m
Storage Environment	-20~50℃, 0~85%RH (no condensing)
Standard Accessory	Power Adapter, User Guide, CD Disk(PC Software), USB cable, Standard Calibration Board, Black Calibration Cavity, Transmission black baffle, Sample holder, 25.4 caliber, 8 caliber, 4 caliber
Optional Accessory	Micro-printer, Transmissive Test Component, Micro Aperture(4mm) transmission test clamp component, Instrument inversion components
Notes: The specifications are subject to change without notice.
